Allen Head Swage

$0.00
Quantity:
Contact for Details
AR PRODUCT DATABASE (+HTML) - AF02 - Allen Head Swage


    Available Variations:
    Handedness: Left Hand-L or Right Hand-R

                    PART NO.
                    Name
                    Wire Size
                    A
                    B
                    C
                    Ø


                    mm
                    Inch
                    mm
                    Inch
                    mm
                    Inch
                    mm
                    Inch
                    mm
                    Inch



                    AHS04
                    Allen Head Swage, 3mm / Short
                    3.0
                    1/8
                    35.0
                    1 3/8
                    27.0
                    1 2/32
                    9.5
                    3/8
                    6.4
                    0.250


                    AHS05
                    Allen Head Swage, 4mm
                    4.0
                    5/32
                    50.0
                    1 31/32
                    39.0
                    1 17/32
                    12.7
                    1/2
                    7.5
                    0.297


                    AHS06
                    Allen Head Swage, 5mm
                    5.0
                    5/32
                    50.0
                    1 31/32
                    39.0
                    1 17/32
                    12.7
                    1/2
                    8.8
                    0.345
