Architectural Swage Stud

$0.00
Quantity:
Contact for Details
Available Variations:
Units: Metric-M or Imperial-I
AR PRODUCT DATABASE (+HTML) - AF05 - Architectural Swage Stud


                    PART NO.
                    Name
                    Wire Size
                    Body Thread
                    A
                    B
                    C


                    mm
                    Inch
                    UNF
                    mm
                    Inch
                    mm
                    Inch
                    mm
                    Inch



                    ASS04-1-4
                    Architectural Swage Stud 3mm Stud With 1/4"
                    3.0
                    1/8
                    1/4
                    76.0
                    2.000
                    32.0
                    1 1/4
                    36.0
                    1 13/32


                    ASS05-1-4
                    Architectural Swage Stud 4mm Stud With 1/4"
                    4.0
                    5/32
                    1/4
                    76.0
                    2.000
                    32.0
                    1 1/4
                    36.0
                    1 13/32


                    ASS06-1-4
                    Architectural Swage Stud 5mm Stud With 1/4"
                    5.0
                    3/16
                    1/4
                    76.0
                    2.000
                    32.0
                    1 1/4
                    36.0
                    1 13/32
